Engineered for secondary and tertiary crushing applications in mining, aggregates, and construction, providing high output and uniform product granularity.
Features a robust design that ensures superior performance and longevity in demanding environments like metallurgy, construction, and quarrying.
Delivers higher crushing efficiency and lower operating costs compared to traditional spring cone crushers.
Achieves exceptional product fineness and uniformity, critical for high-quality aggregate and mineral processing.
Incorporates a hydraulic adjustment system for quick and easy changes to the discharge setting, minimizing downtime.
Constructed with high-manganese steel for wear parts, providing extended service life and reduced maintenance requirements.
Model Series: PYS-B / PYS-D
Movable Cone Diameter: 914 mm to 2134 mm (3 ft to 7 ft)
Max Feed Size (Opening Side): 102 mm to 460 mm
Discharge Opening Range: 3 mm to 64 mm
Processing Capacity: 10 to 1498 t/h
Motor Power: 75 kW to 380 kW
