Spring Cone Crusher
Cone crusher is widely applied in metallurgical, construction, road building, chemical and phosphatic industry.
Cone crusher is suitable for hard and mid-hard rocks and ores, such as iron ores, copper ores, limestone, quartz, granite, gritstone, etc. Type of the crushing cavity is decided by the application of the ores. Standard type is for PYZ (secondary crush); middle type is for PYD (tertiary crush); short-head type is for primary and secondary crush.
SBM’s core business is the supply of world class crushing and screening, specialising in the supply of cone crusher .
Spring Cone Crusher PDF
Cone Crusher Features
1. high productivity; high quality
2. less machine stop time
3. easy maintenance and low cost
4. unique crushing ability in primary, secondary and tertiary crushing
Cone Crusher Structure & operation principles
Cone crusher consist of frame, transmission device, hollow eccentric shaft, bowl-shaped bearing, crushing cone, springs and hydraulic pressure station for adjusting discharge opening.
During operation, the motor drives the eccentric shaft shell to turn around through ahorizontal axle and a pair of bevel gear. The axle of crushing cone swings with the force of eccentric shaft shell so that the surface of the crushing wall is close to the roll mortar wall from time to time. In this way, the ores and rocks will be pressed and crooked and crushed.
Cone Crusher Technique paramete |
Model |
weight (T) |
power |
diameter of cone crusher at big end(mm) |
width of feed opening
(mm) |
max feeding size |
adjustment range of discharge opening |
capacity
(t/h) |
PYB |
600 |
5 |
30 |
Ф600 |
75 |
65 |
12-25 |
20-40 |
PYD |
Ф600 |
40 |
35 |
2-13 |
12-23 |
PYB |
900 |
11.2 |
55 |
Ф900 |
135 |
115 |
15-50 |
60-105 |
PYZ |
Ф900 |
70 |
60 |
5-20 |
50-90 |
PYD |
Ф900 |
50 |
50 |
3-13 |
20-65 |
PYB |
1200 |
35 |
130 |
Ф1200 |
170 |
145 |
20-50 |
110-168 |
PYZ |
Ф1200 |
115 |
100 |
8-25 |
42-135 |
PYD |
Ф1200 |
60 |
50 |
3-15 |
18-105 |
PYB |
1750 |
50.2 |
160 |
Ф1700 |
250 |
215 |
10-30 |
280-480 |
PYZ |
Ф1700 |
215 |
185 |
10-30 |
115-320 |
PYD |
Ф1700 |
100 |
85 |
5-15 |
75-230 |
PYB |
2200 |
80 |
260
280 |
Ф2200 |
350 |
300 |
30-60 |
590-1000 |
PYZ |
Ф2200 |
275 |
230 |
10-30 |
200-580 |
PYD |
Ф2200 |
130 |
100 |
5-15 |
125-350 |
|
For secondary/tertiary crushing operations, SBM manufacture a full line of cone crushing units.
Note: This specification is just reference, any changes are subject to the cone crusher products. |
As the professional cone crusher manufacturer, SBM will provide you with the most professional crushing equipments and all-around services. You are welcome to SBM China for detailed information about our Cone Crusher Machine.
